Single-Link DVI Fiber Optic Extender, 4x LC
Single-Link DVI Fiber Optic Extender, 4x LC
Model No:  DVI-7311

$450.00

Availability: Usually ships the next business day






The DVI-7311 is a low-cost, high performance DVI Optical Extender capable of transporting high resolution DVI signals up to 500 meters (1,640 ft.). The unit consists of an optical transmitter module that converts the DVI input signals into light pulses for transmission over 4 strands of multi-mode fiber optic cable, and an optical receiver module that converts the light pulses back to a DVI signal for display on a monitor or projector. A programmable memory chip in the transmitter module provides EDID support for any display, thereby eliminating the need for copper cables. These features make the DVI-7311 the ideal solution for all display applications that require flawless DVI signal quality over very long cable runs.

Key Features:

  • Supports cable lengths up to 500 meters (1640 ft.)
  • Supports HDTV resolutions up to 1080p, and PC resolutions up to 1920x1200
  • Optical fiber transmission is immune to environmental signal noise

  • Low RFI / EMI profile for sensitive applications
  • User-programmable EDID memory, eliminates the need for DDC connection
  • Detachable optical cables greatly simplify installation and maintenance.
Performance:
Compliance DVI v1.0
Maximum Pixel Clock Frequency 165 MHz
Maximum Video Bit Rate 1.65 Gbps (single-link)
Supported Color Depth 8-bit
Supported HDTV Formats 480i, 480p, 576i, 576p, 720p, 1080i, 1080p, and 2048x1080
Supported PC Resolutions Up to 1600x1200 and 1920x1200
Digital Audio Support None
Connections:
DVI Input / DVI Output 1x 18+1 DVI-D male connector
Optical 4x LC fiber optic connectors
Power Inputs 1x 3.5mm jack
Optical:
Optical Technology / Wavelengths 4x Discrete Optical Channels
Optical Wavelength(s) 850 nm
Optical Transmitter Tx Module: 4x 850 nm VCSEL, Class 1 laser product
Optical Receiver Rx Module: 4x GaAs PIN Photo Diodes
Optical Transmitter Output Power -8 dBm (minimum) / -3 dBm (maximum)
Optical Receiver Input Sensitivity -18.5 dBm (minimum) / -3 dBm (maximum)
Optical Link Power Budget 9.0 dB (minimum)
Cable:
Fiber Cable Type / Max. Length 50/125μ LC Multi-Mode Fiber with 4x LC connectors / 500 meters
DVIGear Fiber Cable OFNP, Plenum Rated - additional data and custom lengths available on request
Cable Jacket OFNP, Plenum Rated, Black PVC Jacket
Cable Outside Diameter 5.0 mm
DDC Support:
EDID Support An EDID memory built into the Tx module can learn and store the display's EDID info.
HDCP Support HDCP communications are NOT supported!
Mechanical:
Construction High impact plastic enclosure with black satin finish
Dimensions (L x W x H) 2.5" x 1.7" x 0.6" (64.2 mm x 42.6 mm x 15.9 mm)
Net Weight DVI-7311-TX: 1 oz. (28 g)    DVI-7311-RX: 1 oz. (28 g)
Environmental:
Temperature Operating: 32° to +158° F (0° to +70° C)
Storage: -40° to +185° F (-40° to +85° C)
Humidity Operating: 5% to 80% (non-condensing)
Storage: 5% to 95% (non-condensing)
Power Requirements:
Optical Transmitter Tx module requires at least 320 ma of DC current from pin 14 of DVI (source) connector.
Optional external power supply may be used if needed.
Optical Receiver Must be powered using the supplied external power supply
External AC Power Adapter Input: 100-240VAC / 50-60Hz 0.2A    Output: 5VDC, 3.0A
Power Consumption DVI-7311-TX: 1.6 watts    DVI-7311-RX: 1.4 watts
Regulatory Approvals:
Fiber Optic Extender Unit FCC, CE, RoHS
AC Power Adapter FCC, CE, UL, C-UL, CEC, GS, PSE, RoHS
Warranty:
Limited Warranty 3 Years Parts and Labor
Model Numbers:
DVI-7311 DVI Single-Link Fiber Optic Extender, 4x LC
DVI-7311-TX DVI Single-Link Fiber Optic Transmitter, 4x LC
DVI-7311-RX DVI Single-Link Fiber Optic Receiver, 4x LC
DVI-CUST-OPT 4x LC, Plenum-rated, Single-Link DVI Fiber Optic Cable (length must be specified)
Accessories Included:
1x External AC Power Adapter with USA plug, 1x User Guide
Optional Accessories:
External AC Power Adapter (with USA, Euro, UK, or Australia plugs) for DVI-7311-TX Transmitter unit
